Rental And Installation LED Stadium Screen Die-Cast Aluminum Screen Pitch 3.91mm, 500*1000mm Full Color Outdoor Video Wall

Product Categories
Shenzhen ShiXin Display Technology Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Rental And Installation LED Stadium Screen Die-Cast Aluminum Screen Pitch 3.91mm, 500*1000mm Full Color Outdoor Video Wall

Brand Name : Shichuangxinke

Model Number : SCXK-P3.91

Certification : CE RoHS FCC CCC TUV UL

Place of Origin : China ,Guang Dong

MOQ : negotiation

Price : negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 5000sqm per month

Delivery Time : 7-10 working days after deposit payment received

Packaging Details : wooden box flight case, wooden case, carton, it is up to you.

Resolution/mm : 3.91

Pixel configuration : 1R1G1B

Scanning Mode : 1/8 scanning

Module Size : 250x250MM

cabinet size : 500x1000MM

certificates : CE RoHS FCC CCC UL

application : stadium,airport,shopping mall,street advertising

material : aluminum

warranty : 3-5 years

Contact Now

Kinglight LED display Pitch3.9mm RGB full color outdoor videowall for movie and cartoon


We are a professional LED display screen manufacturer and supplier in China. Our primary products include indoor LED display screen, outdoor LED display screen, indoor rental LED screen, stadium LED display screen, LED curtain, LED ceiling light, and LED panel light.
P4 LED Display Screen P5 LED Display Screen P6 LED Display Screen P7 LED Display Screen P8 LED Display Screen P10 LED Display Screen



Applications:
Airport Full Color Indoor LED displays advertising
Train station Indoor Full Color LED Displays
Entertainment Bar Indoor Full Color LED Screen
Stadium Indoor Full Color LED Display
Museum Full Color Indoor LED display
Car exhibition LED display
Conference room Indoor Full Color LED Video Display
Shopping Mall Indoor Full Color LED display


Specifications :

outdoor DIP P3.91
Resolution/mm3.91
Pixel configuration1R1G1B
Pixel density/pixels/m²65410/m²
Module resolution64x64
Module size/mm250x250MM
View distance14-300m
Single point brightness adjustCan be added
Single point color adjustCan be added
White balance brightness>7500cd/㎡
Color temperature6500K-9500K
Horizontal view angle120(degrees)
Vertical view angle60(degrees)
Signal Process bit10 or 16bit
Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distancesInternet cable:100m, multimembrane:500m, monofilm:2km
Driving modeConstant driving current
Scanning mode1/8 SCANNING
Frame rate60Hz
Refresh frequency>3000Hz
Control modeComputer synchronous
Brightness adjusted rangeManual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point<1/10000
Working hours≥72hours
Mean Time Between Failure>5000hours
Life time100000hours
Life-all-white(brightness halving)50000hours
Environment temperature rangeOperating temperature range: -20-45℃
Self-check technologyLED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoringRemote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environmentWindowsNT,Windows1999,WindowsXP
Luminous point width between centresDeviation<3%
Brightness uniformity<10%
Color uniformity(chromaticity coordinate)±0.003
Power supply requestAC85-264V(50Hz-60Hz)
Contrast(1000:1)
System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)working:10-95%
Humidity(storing)storing:10-95%




Other Products:

Indoor Rental LED Screen Vivid color performance. The full screen reaches high conformity on both color and brightness. High contrast ratio, high refresh rate, the image is performed well through the LED screen without any delay phenomenon.Each specified LED cabinet ...

Rental LED ScreenConventional electric screens such as CRT video walls, rear projection video walls, front projection screens, plasma display panels (PDP), etc. have limited applications due to their insufficient brightness, size limitation, and installation difficulty ...

Stadium LED Display Screen .For outdoor stadium video screen, we use visual pixel technology to realize better performance of vivid video display. For indoor sports video screen, we use SMD 3 in 1 technology, which takes wider viewing angle, higher refresh rate ...

LED Curtain.The mechanical structure design takes high efficiency on installation and dismantle required for the rental and staging applications. The most special feature of this product is the transparency, which brings spectators different visual effect by changing the brightness ...

Rental And Installation LED Stadium Screen Die-Cast Aluminum Screen Pitch 3.91mm, 500*1000mm Full Color Outdoor Video Wall
Rental And Installation LED Stadium Screen Die-Cast Aluminum Screen Pitch 3.91mm, 500*1000mm Full Color Outdoor Video Wall
Rental And Installation LED Stadium Screen Die-Cast Aluminum Screen Pitch 3.91mm, 500*1000mm Full Color Outdoor Video Wall
Rental And Installation LED Stadium Screen Die-Cast Aluminum Screen Pitch 3.91mm, 500*1000mm Full Color Outdoor Video Wall
Rental And Installation LED Stadium Screen Die-Cast Aluminum Screen Pitch 3.91mm, 500*1000mm Full Color Outdoor Video WallRental And Installation LED Stadium Screen Die-Cast Aluminum Screen Pitch 3.91mm, 500*1000mm Full Color Outdoor Video WallRental And Installation LED Stadium Screen Die-Cast Aluminum Screen Pitch 3.91mm, 500*1000mm Full Color Outdoor Video Wall


FAQ


Q1: How to help client choose suitable display?
A1:
(1)specific application scenario
(2)viewing distance requirement
(3)display brightness requirement
(4)specific installation environment
(5)budget and cost control

Q2: What about your technical support?
A2: Proffessional engineers are on standby, can offer guidance, on site technical support as required.

Q3: What's the control system?
A3: For synchronization control: Nova, Linsn or Mooncell control system.
For asynchronous control: Onbon or Xixun control system.

Q4: What's the warranty of your LED displays?
A4: We provide 2 years warranty and conditioned lifetime technical support for our LED display products.

Q5: What's your payment method?
A5: Our payment method is T/T 30% as deposit, balancing before delivery.
